News & Changes

Commercial Interiors Library (CIL)

• Introduced a consistent ‘Query’ dialogue for CIL symbols, matching Catalogue Browser and FIKA symbols while retaining existing features such as locating parts, Make Special, option changes, material adjustments, importing, and highlighting.

  A dedicated CIL Tools tab provides tools for:

  • Re-optioning parts

  • Modifying CIL material layers

  • Scaling symbols uniformly using percentages or fractions, or adjusting width, depth and height independently.

• Added support for synchronizing the ‘Experimental Mode’ setting between the CIL Extension and Spec.

Customer Own Materials (COM)

• Added support for COMs at any level of material options in ‘Schemes’ for data symbols.

• Updated the COM dialogue to always display the ‘Add as COM in Calculations’ fields, which remain greyed out until the option is selected.

Others

• Query dialog now features a button for replacing the graphics of an object being queried for special data.
• Added support for displaying manufacturer-supplied material quantities in Calculations when the information is available in the manufacturer data.
• The 'Sketch & Build' Extension is now available for the CET Commercial Interiors Edition.
• Folders for textile companies will show the full company name instead of the acronym code after downloading a material in the Material Portal.

Fixes & Enhancements

Crash Fixes

• Fixed issue with the Flooring Tool crashing when clicking anywhere on the installation pattern screen.

Bug Fixes

Commercial Interiors Library (CIL)

• Fixed problem with weight, volume, width, depth, height, and generic code values not appearing for CIL symbols in ‘Calculations’, weight and volume not appearing in ‘CIL Query’, and these values not exporting correctly for CIL and Data Symbol parts in Configura SIF, OFDA XML, and PMX files.

Ind. Tag/COM

• Fixed problem with changing the ‘IND Tag’ for identical component parts listed together in the Bill of Materials not updating all matching tags in Drawing View.
• Fixed problem with COM materials appearing under unrelated standard material options after being linked to a specific material.

OFDA

• Fixed problem with the OFDA XML export label in Calculations by updating it to align with version 4.02.00.

Order SIF (Configura SIF)

• Fixed problem with exporting sub-features from optional selected features in Configura SIF, OFDAXML, and PMX order exports.

Query

• Fixed problem with the Description field in the Part and Option Special and Add Option dialogs so users can paste multi-line text.

News & Changes

Conveyors

• Introduced a new Conveyor Creator extension that enables manufacturers to build and customize conveyor product catalogs by using the provided Excel templates, publish them directly in CET and distribute them through the marketplace.
• Added a Conveyor Catalogue Creator feature under the Conveyor Settings in Essential Conveyors extension that enables users to create a custom conveyor catalogue under Essential Conveyor extension by using the provided Excel template.

Shelving

• Expanded the Essential Shelving extension with a new Retail Shelving product to support retail and shopfitting layout designs directly in CET using specialized rows, bays, and accessories.

Sketch & Build

• Added new extrusion profiles to Sketch & Build, including standard US table edges and additional trims.

Web Viewer

• Introduced 'Web Viewer Exporter' for Material Handling Edition. The Web Viewer allows exports of CET drawings in a format viewable directly in a web browser. Note that the Extension requires a separate license available in the Marketplace.

Essential Extension Updates

Conveyors

• Added new Curved Merge Rollers spur unit to the Essential Conveyors extension that supports multiple curve angles at merging.
• Improved the logic behind snapping behavior to account for occupied space and prevent conveyors from colliding.
• Improved some properties handling logic for curve and wedge units in Essential Conveyors to prevent unexpected disconnects and reconnections when modifying properties like Curve Angle or Handedness.
• Added property controls to select charge or discharge connectors along with graphic indication to determine the active connector when inserting or moving conveyors.

Deep Racking

• Added support for shuttle support beams to show up in the Bill of Materials with correct dimensions for Essential Deep Racking.
• Added support for frame bracing to show up in the Bill of Materials with correct length measurements for Essential Pallet Racking and Essential Deep Racking.
• Updated the minimum and maximum value for some properties for Essential Deep Racking Shuttle for flexibility in allowable range
• Added support for modifying outer frame height values in Essential Deep Racking Preconfigurator.
• Updated the clearance logic in Deep Racking Pallet Live to remove the restriction involving Load-to-Load and Frame-to-Load values. Clearance behavior is now improved so that setting a Load-to-Load clearance to less than 2 × Frame-to-Load clearance will automatically updates the Frame-to-Load clearance to half of the Load-to-Load value.
  Improved the segment width behavior to ensure that changing the width now updates both Load-to-Load and Frame-to-Load clearance values simultaneously.
• Removed the "Adjust bay" option from collision property during insertion in Deep Racking to ensure consistent and predictable behavior

MH Framework

• Improved performance of moving cursor around when inserting a component with System spread and solved the flickering of some dimension property values.

Mezzanine

• Added new Gate opening property to the Quick Properties for single, double, horizontal, and tilt gates to control the degree of opening for improved visuals.

Fixes & Enhancement

Crash Fixes

Conveyors

• Fixed issue where changing the between frame (BF) value for curve conveyors in quick properties could cause a crash.

Shelving

• Fixed issue that could cause a crash when opening the Bay Editor or Frame Editor for Essential Shelving bays with missing row data.

Bug Fixes

Collaboration Pro

• Fixed problem where CET could become unresponsive shortly after opening the CollabPro dialog.
• Fixed issue that could occur when fetching files in CollabPro after clearing the CollabPro server cache and retrying previously interrupted downloads.
• Fixed issue that could occur when loading a paper section in Collaboration Pro after closing the corresponding section.

Connector

• Fixed problem where all snapping points became visible after switching views when multiple racking bays were selected.

Conveyors

• Fixed problem where invalid curve angle options were offered in the polyline insert animation after placing a straight unit with a stepped length domain.
• Fixed problem where side guards in Essential Conveyors would not respond to unit length changes, preventing them from automatically updating to match the length of the conveyor path.
• Fixed problem where users were unable to switch the conveyor type in the animation properties after the first click when using the Polyline Insert tool.
• Fixed problem where the Conveyor Demo extension would automatically pin itself to the top upon starting CET even when it was unpinned previously.

Selective Pallet Racking

• Fixed problem where applying an NA GMA Pallet to a row or system created inconsistent beam spacing due to an unintended level arrange function triggering during mouse wheel events

Sketch & Build

• Fixed problem where Sketch & Build lines within an assembly remained visible in View Clips and Elevation Views even when filtered out.

News & Changes

General changes

• Added support for adjusting the placement of fans in the x and y directions after insertion.
• Updated naming within the Essential Kitchen EU Extension to 'Kitchen & Bath' in the following areas:
  • Extension toolbox
  • Dialogs
  • Catalogue Explorer
  • Picklist
  • Reports
  • Project Information.

          The Extension’s name in the Marketplace remains 'Essential Kitchen EU'.

• Added support for visualizing sink cutouts in 2D for covering sinks

Improvements

Bug Fixes

General changes

• Fixed problem where the worktop overview was missing from the supplier printout when triggered from the new toolbox.
• Fixed problem where worktops were incorrectly split when placing non-integrated laundry goods, such as tumble dryers and washing machines.
• Fixed problem where some sinks were not visible in the 3D view during placement on cabinets with worktops.

Essential Kitchen backend

• Fixed problem where automeasures for walls were missing.
• Fixed problem with worktops appearing in printed plan views.
• Fixed problem where placing multiple sinks in a worktop resulted in incorrect measurements.
• Fixed a problem preventing the placement of worktops in drawings containing pillars.

Essential Kitchen extension

• Fixed problem where light rail would not automatically adopt to wall cabinets when they were added or removed.
• Fixed problem where 2D and 3D representations for certain models in Essential Kitchen EU did not match their catalog specifications, causing incorrect collision detection and intersections with walls.

Crash fixes

General changes

• Fixed issue where CET could crash when changing handles in the scheme editor.
• Fixed issue where CET could crash when unchecking the 'Select' checkbox in the Countertop properties dialog.
