CET 15.0 Minor: August 19, 2024

 All Editions News & Changes

New Features

Continuous Wall

With the release of 15.0 Minor, we have introduced a new Continuous wall feature in the Wall Drawing tab.

• Continuous Wall Tool: Users can now place walls continuously in a single animation. Once placed, the wall cannot be modified further within the same animation.
• Feature Lines & Reference Points: New optional feature lines and reference points can be enabled/disabled to enhance graphical support for aligning continuous and standard walls.

Assign Objects to Nearest Level

The new 'Assign objects to nearest Level' categorizes objects only to the innermost Level. By using this setting, you can now only move objects categorized to the active Level while editing it.

Fixes & Enhancements

Improvements

• The Wall drawing tools now support simultaneous locking of angles with X or Y values for better wall insert flexibility.
• The Positioning tool now supports precise elevation of the Z-axis at a 90-degree pitch that can be controlled with a mouse cursor.
• The Align tools have been updated to include additional alignment options.
• Added a new Import button to the Tools component tab menu in the new UI.
• Added additional information to the error reports along with a copy of the log sent by the user.
• Renamed 'Fill background' in dimension properties to 'Text highlight' for clarity.
• Updated the Quick Properties text field in Dimensions to reflect changes. The undo step now includes the entire string.
• Two-Click Dimensions can be used to place dimensions with just two clicks.
• RevLink now supports Revit 2025.
• Added 'Decal' as a new category to the Filter dialog in CET Material Handling.
• Changed the minimum length of straight Pallet Conveyors to 12" instead of 72".
• Increased the size limit of nestable totes and case totes.
• Added a new spread option when moving the bracing in Essential Cantilever.
• Added the Conveyor Decal to the Conveyor Scheme. This property can now be applied to existing decals in drawings or used when inserting a new decal.

Crash Fixes

• Fixed issue that could cause a crash when switching between the old and new UI in certain conditions.
• Fixed issue with CET startup performance by automatically removing obsolete files, preventing them from being imported repeatedly, which could cause a crash.
• Fixed issue where clicking on the unit of a dimension could cause a crash.
• Fixed issue where opening the Control Panel could cause a crash by another graphic engine.
• Fixed issue that could occur when opening 'View backups and autosaves' when essential header data is missing or the file is corrupted.
• Fixed issue where changing the Center-to-Center of Straight Chain Conveyor from a saved favorite file would crash CET.
• Fixed issue that could occur when adjusting the length of the Narrow Belt Sorter Conveyor.
• Fixed issue that could occur when inserting a back panel to shelving with the Allow Replace option checked.
• Fixed issue with the Bay Editor where creating a new configuration with the number of unit loads set to 0 caused a crash.
• Fixed issue where using undo after inserting a racking system with auto part tags enabled could cause a crash.

Bug Fixes

• Fixed problem where, in rare cases, a DWG import could import a previously imported DWG instead of the current one selected.
• Fixed problem where CET incorrectly identifies the user's operating system version.
• Fixed problem where the filename placeholder was missing in the ‘Save As’ dialog text field.
• Fixed problem where the detailed tooltips were blocking the objects in the drawing.
• Fixed problem where the tooltip was missing when hovering over the options in the drop-down menus.
• Fixed problem where Visibility Settings were occasionally not applied.
• Fixed problem where the window blinds in wall accessories could not stretch or resize correctly.
• Fixed problem where exiting a block after editing navigates back to the wrong alternative.
• Fixed problem where the dash was not displayed when the inch value was 0 in the 'feet and inches' Distance Unit.
• Fixed problem with Scheme not applying feature option with sync group code to symbol.
• Fixed problem where the scheme was incorrectly applied to unchecked properties.
• Fixed problem with product codes not showing in the View All mode when a catalog product is missing an Ind. Tag.
• Fixed problem where the price preview could not be hidden by modifying the work mode.
• Fixed problem where drop-down options in the Calculation list would open while scrolling the BOM.
• Fixed problem with the manufacturer code column in Calculations missing the enterprise code data from catalogs.
• Fixed problem with help points that, in Paper View, could cause them to suddenly become very large in size if the 2D position was changed in the quick properties box.
• Fixed problem where a created PDF could become unnecessarily large in size.
• Fixed problem where the Collaboration Tab does is not able to reach the bottom of the Section or Paper list.
• Fixed problem with material swatches not generating the correct material image from the Finish Legend using the FIKA Extension products.
• Fixed problem with symbol text from the Symbol Library Extension not showing in the normal View Mode or Viewports.
• Fixed problem where the furniture category was missing in the RevLink Add-in setting for Revit 2024.
• Fixed problem where the Configura SIF and Custom SIF did not retain the base and option pricing in Worksheet.
• Fixed problem with options not applying to a Commercial Interior Library (CIL) picklist item after a query and re-optioning.
• Fixed problem where CET Material Handling did not use concrete as the default flooring.
• Fixed problem to include the m/min and the correct zone quantity in the Essential Conveyor Excel report.
• Fixed problem where using a decimal in the Conveyor Pricing Excel report resulted in empty pricing.
• Fixed problem where the Pallet Roller Transfer did not correctly align with a rotated Straight Pallet Chain Conveyor.
• Fixed problem where the flue space was not displayed as an adjustable property in the Preconfigurator for Essential Shelving.
• Fixed problem in Essential Shelving where the number of levels was reset to the default value after all levels in the bay were removed.
• Fixed problem where a shelf could not be selected after inserting a support beam.
• Fixed problem where the favorite file did not retain the correct orientation of the shelf.
• Fixed problem where dividers were misaligned when placed in double-row shelving.
• Fixed problem where the Frame Editor was not displaying all available frame configurations in the drawing.
• Fixed problem where the level beam could exceed the frame height after adjusting the bay height for drive-in deep racking.

• Fixed problem where the side fence did not align correctly when copied and pasted to double row deep racking.

• Fixed problem where stretching a bay width with Top Approach and Aisle Spacers checked did not change the adjacent bay width.

• Fixed problem where the Arm-to-Arm Clearance did not restore to the previously entered clearance after undo.

• Fixed problem with the Bay Editor where, after removing all levels, changing the number of levels would always revert to one.

• Fixed problem where the incorrect bay configuration appeared in a loaded drawing until the Bay Editor was opened.
• Fixed problem where the Level Elevation displayed an incorrect range of height, preventing adjustments in the Bay Editor.
• Fixed problem where copying and pasting a bay within the drawing did not generate the uprights.
• Fixed problem where removing the bay from a row with only a single bay will also remove the row.
• Fixed problem where the flue gap remained at 100mm in the Quick Properties.

• Fixed problem where the Unit Load Editor failed to display the 3D preview when the main drawing space was in Layout view.

• Fixed problem where the bracing on the landing support would disappear after adjusting the height.
