Summary

The Missing Catalog warning appears when a drawing references one or more catalogs that are no longer available. This can happen if a catalog has been removed or decommissioned by the manufacturer, or if access to a beta catalog has been revoked.

In many cases, this warning is informational and does not indicate a problem with the drawing.

Details

When the warning appears, select Show Details to view additional information about the affected catalogs and extensions.

This information can help identify which catalogs are missing and whether they may impact the drawing:

What should I do?

Step 1: Check the Drawing

Review the drawing to determine whether any symbols appear as question mark boxes or are otherwise missing.

• If all symbols display correctly, you can safely dismiss the warning and continue working.
• If symbols are missing, continue to Step 2.

Step 2: Contact Support

If the drawing contains missing symbols, please contact Configura Support for assistance.

When contacting Support, include:

• The drawing file (.cmdrw)
• A screenshot of the Missing Catalog warning (including Show Details, if possible)

This will help us identify the missing catalog more quickly.
